Lighting Poles & Brackets
POLES AND BRACKETS
PHINIX TECHNOLOGY offers M.S. pole and bracket mounting solutions that complement our wide variety of outdoor area lighting and roadway lighting fixtures. Choose pole designs and heights of up to 30 feet (9 meters) and also by th requirement of customers. Many of our poles and brackets also accommodate single or multiple luminaire mounting, giving you greater flexibility in your outdoor lighting design.
Street Light Bend Angle For RCC Pole
| Arm Length | 1.25 Feet Round M.S. Pipe with 1" Diameter |
| Arm Base | 1 Feet Square M.S. Pipe of pair |
| Arm Angle | Minimum 30 Degree from Horizontal Plane |
| Coating | Iron Oxide(Red or Yellow oxide) and Paint |
Street Light Brackets
| Arm | Sigle Arm OR Double Arm |
| Arm Lenght | 1 Mtr to 3 Mtr Round M.S. Pipe with 1" to 2" Diameter |
| Arm Base | Minimum 1 Feet Round M.S. Pipe with 3" to choice of Diameter |
| Arm Angle | Minimum 30 Degree from Horizontal Plane |
| Coating | Iron Oxide(Red or Yellow oxide) and Paint |
Applications
- Street Lighting
- Industrial Lighting
- Highway Lighting
- Area lighting-party plot
Street Light Pole
| Height | 5 Mtr, 6 Mtr, 7 Mtr |
| No. of Sections | Two, Three |
| Material | Mild Steel |
| Base Pipe | 4" or 5" diameter with 2.5 to 3.5 mm Thickness |
| Top Pipe | 2", 3" or 4" diameter with 2 to 3 mm Thickness |
| Bottom Plate | 1 * 1 Feet or 2 * 2 Feet Square with 10 to 12 mm Thickness |
| Bracket for light fixtures | Single arm, double arm or customer choice |
| Number of foundation Bolts | Four |
| Paint | Anti-corrosive, Oil paint or PU paint options are available |
Applications
- Street Lighting
- Industrial Lighting
- Highway Lighting
- Area lighting-party plot
Features
- Customized options are also available
- Burial type or Anchor bolt type foundation
- Very economic design for fitting & maintenance of light fixture
Ladder Type Lighting Pole
| Height | 9 Mtr, 12 Mtr, 15 Mtr |
| No. of Sections | Two, Three or Four |
| Material | Mild Steel |
| Base Pipe | 4" or 5" diameter with 2.5 to 3.5 mm Thickness |
| Top Pipe | 2", 3" or 4" diameter with 2 to 3 mm Thickness |
| Bottom Plate | 1 * 1 Feet or 2 * 2 Feet Square with 10 to 12 mm Thickness |
| Ladder | 1 * 1 Square Pipe |
| Bracket for light fixtures | Single ring type, double ring type or customer choice |
| Number of foundation Bolts | Four |
| Paint | Anti-corrosive, Oil paint or PU paint options are available |
Applications
- Yard lighting
- Industrial Lighting
- Road Lighting
- Architectural lighting
- Area lighting-party plot
- Sports complex Etc.
Features
- Customized options are also available
- Burial type or Anchor bolt type foundation
- Very economic design for fitting & maintenance of light fixture
- Monkey ladder or clit & hook arrangement for climbing purpose
